Anova Pro

฿72,900.00

***Barn Doors are not included***

Bi-Colour (6300K-3150K) ‘STANDARD’ 50 beam angle (No Battery Bundle)

Out of stock

Categories: , , Tags: , , , ,

Description

Rotolight Anova Pro is the ultimate LED studio/ location light designed for the most demanding of professionals. Anova Pro’s Bi-Colour LED system with AccuColour™ delivers exceptional colour rendering (CRI:96+) and powerful soft light output, making it ideal for cinematographers, videographers and photographers, whilst using 94% less energy than a standard tungsten bulb.

Anova PRO represents the pinnacle of LED technology, with five unique innovations:  CINESFX ™  Provides an powerful arsenal of Cinematographic Lighting FX (CineSFX™) for use on set or location.  HIGH SPEED SYNC FLASH provides a powerful HSS flash at 150% of the maximum continuous light output for traditional photographic workflows.   TRUE APERTURE DIMMING ™ calculates and displays the correct aperture (F-Stop) for your subject at a given distance and DESIGNER FADE ™ provides custom fade up / fade down production effects.

Powered by V-Lock or mains power, ANOVA™ delivers a powerful output (up to 6545 Lux at 3 feet), whilst using 94% less energy than a standard tungsten bulb.  Anova Pro delivers unparalleled versatility, superior colour rendering and gorgeous soft light output and is ideal for cinematographers, videographers and photographers alike.

Available in either Bi-Colour (6300K-3150K) ‘STANDARD’ 50 beam angle, which is our recommended choice for the majority of applications to maximise the versatility of this innovative light, or fixed colour 5600K, the brightest model in the range – ideal for photographers who are concerned with maximum light output and also for those who primarily work outdoors. A special 110 ‘ULTRAWIDE’ Bi Colour model is also available (for soft-fill, or Chromakey background illumination) which naturally spreads the light over a much wider area without the need for diffusion, at a correspondingly lower illumination level.

ADDITION INFORMATION

Colour Temperature Range Electronically Adjustable from 3150K – 6300K
TLCI 91
Overall CRI (RA) CRI=>96 (Skintone R15 CRI=99)
Guide Number GN 24@ISO 100@9ft
LUX at 3ft **(0.9m) 6280 Lux
Foot Candles (fc3ft) 583 fc
Lumen (3ft) 3091 Lumens
f Stop at ISO 200/400/800 (3ft) f8 / f11 / f16
Lux at 6ft **(1.8m) 1760 Lux
Foot Candles (fc 6ft) 164
Lumen (6ft) 3466 Lumens
f stop at ISO 200/400/800 (6ft) f4.59 / f6.5 / f9.19
Lux at 9ft ** (2.7m) 857 Lux
Foot Candles (fc 9ft) 80 fc
Lumen (9ft) 3795 Lumens
f stop at ISO 200/400/800 (9ft) f3.73 / f5.28 / f7.46
Power Consumption @ 100% Output 48 Watts @ 100% Output
Control Flash sync and trigger input
Weight 2.47kg (3.34 Kg with Yoke), 4.78kg with Yoke and Barn Doors
Dimensions 440mm (Width) x 493mm (Height) x 107mm (Depth)
Mounting via Standard TVMP Bracket on Yoke or M8 via Utility Block
Beam Angle Bi-Colour 50º(recommended), Bi-Colour 110º degree, Fixed Colour 5600K
Masters Kit No Masters Kit, Yes Masters Kit – (Inc. barn doors & Flight Case)
Battery Bundle No Battery Bundle, 1 Battery + DTap Travel Charger, 1 Battery + 2 Way Charger, 2 Batteries + 2 Way Charger, 4 Batteries + 4 Way Charger
Included Filters 216 Full Diffuser, 250 Medium Diffuser, 184 Cosmetic peach, 279 1/8 Minus Green, 248 1/2 Minus Green

FEATURES

CINESFX™  is a powerful suite of customizable Lighting FX (CineSFX™) for Television production and feature film applications. These include all the common lighting effects that gaffers and DOPs are frequently required to recreate on set, from fire, lightning, TV, film, neon and spark simulation, to more novel effects, such as police, paparazzi and gunshot visual effects. CineSFX™ eliminates the need for legacy ‘flicker box’ workflows, saving significant time and cost to achieve powerful lighting FX, and can also be used with a wireless trigger for remote control.

FX SLAVE™ enables the CineSFX ™ effects to be slaved to up to 512 third party light sources in real time with zero latency to create powerful lighting effects for large scale productions.

HIGH SPEED SYNC FLASH (HSS) provides a powerful HSS flash with zero recycle time, at 150% of the maximum continuous light output, for use in traditional photographic workflows. Also includes a modelling light capabilty, along with control of flash duration and colour temperature, combining the advantages the best of both legacy strobe technology and continuous ‘shoot what you see’ light output.

TRUE APERTURE DIMMING™ calculates and displays the correct aperture (F-Stop) for your subject at a given distance, revolutionizing your workflow by eliminating the need for metering. Alternatively, dynamically adjust your brightness level, to work at your desired aperture (F-Stop).

DESIGNER FADE™ mode provides custom fade up / fade down interview/ production effects for DSLR videographers and creative cinematographers, reducing time required in post production.

GUIDE NUMBER + F-STOP TABLES

Screen Shot 2016-07-15 at 16.07.09

IN THE BOX

1 x Rotolight ANOVA PRO™
1 x Yoke with Standard TVMP Bracket
1 x Rotolight Universal power adapter with regional mains cable
1 x Gel Filter Holder
1 x User ANOVA PRO™ manual
1 x ANOVA PRO™ Filter Pack:
1 x 216 Full Diffuser (1.5 Stops)
1 x 250 Medium, Half White Diffuser (3/4 Stops)
1 x 184 “Cosmetic Peach” Diffusion
1 x 279 1/8th Minus Green (Magenta)
1 x 249 1/4 Minus Green (Magenta)
1 x 248 1/2 Minus Green (Magenta)

DOWNLOADS

Anova Pro Brochure – PDF Download link
Anova Pro Collection link
Anova Pro User Manual – PDF Download link
